Choice: Polyester 12～60μm; NylonFilm 15～60μm; Polyethylene 40~75μm; OPP/BOPP/CPP Polypropylene Film 15~60μm; Polywinyl Chloride 25~65μm; Cellophane 20～30μm; Paper 30~80g/m2
Every control module of the automatic color register system is equipped with micro-processor and can correct the deviation of color register quickly and accurately.
Each printing unit is driven by servo motor.
Double station for unwind and rewind,non-stop material splicing.
The unwind and rewind units are equipped with variable frequency drives and a closed-loop tension control system.
The unwind/rewind traction is driven by servo motors, integrated with a closed-loop tension control system.
Closed oven and independent heating hot air blowing system,automatic constant temperature system.
Pneumatic impressing system and pneumatic doctor blade system.
Diaphragm-type pneumatic ink auto circulating system.
Air shaft for unwinding/rewinding material loading.
Printing linear speed and meter counting display.
Non-shaft for loading material.
Equipped with ink transfer roller.
Equipped with heat energy saving system.
| Model | AZJ-8850E | AZJ-81050E | AZJ-81250E |
| Max. Width of Web | 850mm | 1050mm | 1250mm |
| Mechanical Max. Speed | 520m/min | 520m/min | 520m/min |
| Max. Printing Speed | 500m/min | 500m/min | 500m/min |
| Max. Unwind-Rewind Diameter | Φ800mm | Φ800mm | Φ800mm |
| Internal Diameter of Roll Core of Substrate | Φ76mm | Φ76mm | Φ76mm |
| Diameter of Printing Cylinder | Φ120-300mm | Φ120-300mm | Φ120-300mm |
| Register Accuracy | ±0.05mm | ±0.05mm | ±0.05mm |
| Tension Range | 3-40kg | 3-40kg | 3-40kg |
| Heating Power of Drying Oven | 300kw | 305kw | 310kw |
| Total Power | 410kw | 420kw | 430kw |
| Weight | About 45000kg | About 47000kg | About 49000kg |
| Overall Dimension (L*W*H) | 18300*4300*3400mm | 18300*4500*3400mm | 18300*4700*3400mm |
