Choice: Polyester 12～60μm; NylonFilm 15～60μm; Polyethylene 40~75μm; OPP/BOPP/CPP Polypropylene Film 15~60μm; Polywinyl Chloride 25~65μm; Cellophane 20～30μm; Paper 30~80g/m2
Every control module of the automatic color register system is equipped with micro- processor and can correct the deviation ofcolor register quickly and accurately.
Main motor with inverter speed control.
Turret un/rewinding section, non-stop material splicing.
Unwinding and in-feed section with inverter speed control system and close loop tension control system.
Rewinding and out-feed section with inverter speed control system and close loop tension control system.
Closed oven and independent heating hot air blowing system, automatic constant temperature system.
Pneumatic impressing system and pneumatic doctor blade system
Diaphragm-type pneumatic ink auto circulating system
Inflatable air shaft for unwinding / rewinding material loading
Printing linear speed and meter counting display
Shaft less printing cylinder loading device, printing cylinder is fixed by shaft-less air chuck.
| Model | AZJ-8850C | AZJ-81050C | AZJ-81250C |
| Max. Width of Web | 850mm | 1050mm | 1250mm |
| Mechanical Max. Speed | 220m/min | 220m/min | 220m/min |
| Max. Printing Speed | 200m/min | 200m/min | 200m/min |
| Max. Unwind-Rewind Diameter | Φ600mm | Φ600mm | Φ600mm |
| Internal Diameter of Roll Core of Substrate | Φ76mm | Φ76mm | Φ76mm |
| Diameter of Printing Cylinder | Φ105-300mm | Φ105-300m | Φ105-300mm |
| Register Accuracy | ±0.1mm | ±0.1mm | ±0.1mm |
| Tension Range | 3-25kg | 3-25kg | 3－25kg |
| Heating Power of Drying Oven | 123kw | 147kw | 171kw |
| Total Power | 175kw | 200kw | 225kw |
| Weight | About 25000kg | About 27000kg | About 29000kg |
| Overall Dimension (L*W*H) | 17800*3500*3400mm | 17800*3700*3400mm | 17800*3900*3400mm |
